[C++] 유한체 연산 & 다항식 연산 (S-box 구현 원리)

// Sbox_using_GF.cpp
// Sbox table using calculation of finite field
// FIPS 197 공식 문서 참고

#include <iostream>

typedef unsigned char byte; // new data type : byte - GF(2^8)

// GF print polynomial
void GF_print(byte gf) {

    int coef;

    printf("%d = %02x = ", gf, gf);
    for (int cnt_i = 7; cnt_i >= 0; cnt_i--) {
        coef = (gf >> cnt_i) & 0x01; // using msb
        if (coef == 1) {
            std::cout << " + " << "x^" << cnt_i;
        }
    }
    std::cout << std::endl;
}

// GF(2^8) add func
byte GF_add(byte gf1, byte gf2) {

    return gf1 ^ gf2; // xor
}


// GF(2^8) xtime() func
byte GF_xtime(byte gf) {

    int msb; //x^7의 계수 (최고차항)
    byte result;

    msb = (gf >> 7) & 0x01;
    if (msb == 1) {
        result = (gf << 1) ^ 0x1b;
    }
    else {
        result = gf << 1;
    }
    return result;
}

// GF(2^8) xtime() func
byte GF_xtime_simple(byte gf) {
    return ((gf >> 7) & 0x01 == 1 ? (gf << 1) ^ 0x1b : gf << 1);
}


// GF(2^8) multi
// f(x) = a0 + a1*x + a2*x^2 + a3*x^3 + ... + a7*x^7
// h(x) = g(x)*f(x)
//        = g(x)*a0 + g(x)*a1*x + g(x)*a2*x^2 + g(x)*a3*x^3 + ... + g(x)*a7*x^7
//        = g(x)*a0 + x*( g(x)*a1 + g(x)*a2*x + g(x)*a3*x^2 + ... + g(x)*a7*x^6 )
//        = g(x)*a0 + x*( g(x)*a1 + x* (g(x)*a2 + g(x)*a3*x + ... + g(x)*a7*x^5 ))
//        = g(x)*a0 + x*( ... x*( g(x)*a7 ) )

byte GF_mul(byte f, byte g) {

    byte h; // 곱셈 결과 h(x) = f(x) * g(x)
    int coef; // 계수
    h = 0x00;
    for (int i = 7; i >= 0; i--) {
        coef = (f >> i) & 0x01; // a7, a6, a5, ... a0
        h = GF_xtime(h);
        if (coef == 1) {
            h = GF_add(h, g);
        }
    }
    return h;
}

// GF(2^8) 역원
// ( a^255 = 1 )임을 이용한다.
// a^(-1) = a^(254) = a^2*a^4*a^8*a^16... *a^128
//          = a^(1111 1110) = a^(1000 0000) * a^(0100 0000) ... * a^(0000 0010)

byte GF_inv(byte f) {
    byte f_inv; // 역원 (결과값)
    byte temp; // 중간에 곱할 값 (a^n) a^2, a^4, a^8, a^16, ... a^128
    f_inv = 1;
    temp = f;
    for (int i = 0; i < 7; i++) {
        temp = GF_mul(temp, temp);
        f_inv = GF_mul(f_inv, temp);
    }
    return f_inv;
}

// AES Affine Aw+b (Affine 변화)
// w = x^(-1)

byte AES_Affine(byte w) {

    byte A[8][8] =
    {
    {1, 0, 0, 0, 1, 1, 1, 1},
    {1, 1, 0, 0, 0, 1, 1, 1},
    {1, 1, 1, 0, 0, 0, 1, 1},
    {1, 1, 1, 1, 0, 0, 0, 1},
    {1, 1, 1, 1, 1, 0, 0, 0},
    {0, 1, 1, 1, 1, 1, 0, 0},
    {0, 0, 1, 1, 1, 1, 1, 0},
    {0, 0, 0, 1, 1, 1, 1, 1}
    };

    byte b_vec[8] = { 1, 1, 0, 0, 0, 1, 1, 0 };
    byte w_vec[8], y_vec[8], y;

    for (int i = 0; i < 8; i++) {
        w_vec[i] = (w >> i) & 0x01;

    }

    for (int i = 0; i < 8; i++) {
        y_vec[i] = b_vec[i];
        for (int j = 0; j < 8; j++) {
            y_vec[i] ^= A[i][j] * w_vec[j]; //b 에다가 행렬곱을 더해준 것
        }
    }

    y = 0;
    byte temp_bit;
    for (int i = 0; i < 8; i++) {
        temp_bit = y_vec[i] << i;
        y ^= temp_bit;
    }
    return y;
}

// AES S-box
void Get_AES_Sbox(byte sbox[256]) {
    byte temp;
    // 0^(-1) = 0 으로 간주한다.
    sbox[0] = AES_Affine(0);
    for (int i = 1; i < 256; i++) {
        temp = GF_inv(i);
        sbox[i] = AES_Affine(temp);
    }
}

// AES Inverse S-box
void Get_AES_Inv_Sbox(byte invsbox[256]) {
    byte Sbox[256];
    Get_AES_Sbox(Sbox);
    for (int i = 0; i < 256; i++) {
        invsbox[Sbox[i]] = i;
    }
}


// test func
void GF_test() {

    byte gf1, gf2, gf3;
    gf1 = 0x04; //x^2 = (0000 0100)_2 = (0x04)_16 = (4)_10
    gf2 = 0x1b; //x^4 + x^3 + x^1 + x^0 = (0001 1011)_2 = (0x1b)_16 = (27)_10

    GF_print(gf1);
    GF_print(gf2);

    gf3 = GF_add(gf1, gf2);
    GF_print(gf3);

    //xtime
    //gf1 = 0x80; // 1000 0000 = 128 = x^7
    gf1 = 0x07;
    gf2 = GF_xtime(gf1);
    GF_print(gf1);
    GF_print(gf2);

    gf1 = 0x10; // 0001 0000
    gf2 = 0x08; // 0000 1000
    gf3 = GF_mul(gf1, gf2);

    GF_print(gf1);
    GF_print(gf2);
    GF_print(gf3);

    gf2 = GF_inv(gf1);
    gf3 = GF_mul(gf1, gf2);

    GF_print(gf1);
    GF_print(gf2);
    GF_print(gf3);


}

void Sbox_test() {
    byte Sbox[256];
    Get_AES_Sbox(Sbox);

    std::cout << "Sbox = ";
    for (int i = 0; i < 256; i++) {
        if ((i % 16) == 0) {
            printf("\n");
        }
        printf("%02x ", Sbox[i]);
    }
    printf("\n");

    byte invSbox[256];
    Get_AES_Inv_Sbox(invSbox);

    std::cout << std::endl << "Inverse Sbox = ";
    for (int i = 0; i < 256; i++) {
        if ((i % 16) == 0) {
            printf("\n");
        }
        printf("%02x ", invSbox[i]);
    }
    printf("\n");
}

int main()
{

    // GF_test();

    Sbox_test();
    return 0;
}
